Capability

Aluminium Extrusion Service

Custom aluminium profiles pushed through a die to your section drawing, cut to length and finished.

Extrusion produces tubes, rods and T, L and U sections in one pass, which makes it the cheapest way to get a long part with a constant cross section.

  • 5 Materials: aluminium, copper, stainless, steel, plastics
  • 1pass Tubes, rods and T, L and U sections
  • Diekept Repeat orders run on the same tooling

How extrusion works at Coler

The process starts with an aluminium billet, heated until it softens. It is then pushed through a die, which shapes it into the profile you drew. Think of squeezing toothpaste from a tube: the metal emerges in the shape of the die opening, anything from a flat bar to a complex T beam or a window frame.

The result is strong and light at once, which is why it suits automotive and aerospace where weight matters, and window, door and curtain walling systems where corrosion resistance decides service life.

Most profiles go straight from the press to anodising, clear or coloured, before we cut them to length. Sections needing work after extrusion move to CNC machining. We also supply the matching T bolts and T nuts, spacers and P clips for the slot, so the framing and the fixings arrive together.

We keep the die, so repeat orders run on the same tooling and the second order costs less than the first.

A new section needs a die. Send the drawing and we will quote the die and the rate together, so you can see where the volume has to land.

Also available

  • Cut to length, deburred and finished before shipping
  • Anodising, painting and powder coating
  • Matching T bolts, nuts, spacers and P clips
  • QC records traceable in system

Order to delivery

From die design to finished aluminium extrusion

Die design through to cut length, with the finishing on the same order rather than sent out.

  1. Profile drawing reviewSection checked for wall thickness, draw ratio and what the die can hold
  2. Die designDesigned around the dimensions you tell us are critical
  3. Die manufactureTooling cut, and kept afterwards for your repeat orders
  4. Trial extrusionFirst profile run and measured against the section drawing
  5. Sample approvedNothing goes to volume until you have signed the sample off
  6. Production runExtruded to rate, in aluminium, copper, stainless, steel or plastic
  7. Quality controlRecorded against the standard and traceable in system
  8. Cutting and finishingCut to length, deburred, then anodised or coated
  9. Packing and deliveryPacked so profiles arrive straight and ready to assemble
  10. Customer aftercareThe die stays with us, so the next order goes straight on

Send a section drawing with the annual volume and we will quote the die and the rate together, so you can see where the tooling pays back.

Request a quote

What decides the cost of an extruded section

  • 01

    Wall thickness

    Drives cost and strength together. A heavier section costs more metal per metre, and can let you drop a bracket elsewhere in the assembly.

  • 02

    Which dimensions are critical

    Tolerance is set by the die and the puller, not a cutting tool. Tell us which ones matter and we design the die around them.

  • 03

    Annual volume

    The die is a one off cost. Repeat orders run on tooling we already hold, so the second order costs less than the first.

  • 04

    Finish

    Anodising, painting or powder coating, quoted on the same order rather than sent out separately.

  • 05

    Cut length

    Profiles cut, deburred and finished on one order, so they arrive ready to assemble.

  • 06

    The fixings

    T bolts, nuts, spacers and P clips for the slot, supplied with the framing rather than sourced separately.

Recent work

Extruded profiles

Sections extruded at Coler, cut to length and finished before they ship.

  • Extruded aluminium profile section.

    Profile section

  • Extruded aluminium sections cut to length.

    Cut to length

  • Complex extruded aluminium cross section.

    Complex cross section

  • Anodised extruded aluminium profile.

    Anodised profile

  • Extruded aluminium framing section with slot.

    Slotted framing

  • Stack of extruded aluminium profiles.

    Profile stock

What is aluminium extrusion?

Extrusion forces aluminium alloy through a die, shaping it into a profile while holding a constant cross sectional area. The results are called extrusions.

The main advantage is complex cross sections at high precision and repeatability, which makes it the practical route for parts with specific mechanical properties or intricate shapes that would be difficult or expensive any other way. Aluminium being light, corrosion resistant and strong for its weight does the rest.

The billet is heated until it is malleable but still solid, transferred to the press and forced through the die. After extrusion the shapes can be anodised, painted or powder coated to improve surface properties or appearance.

Where do extrusions get used?

In construction, extrusion makes framing systems, window and door frames and curtain walling. Those benefit from strength and lightness together, so a structure can be sturdy without being heavy. Resistance to weathering and corrosion is what makes the same section work inside and out.

The automotive sector uses extrusions extensively for structural components, because taking weight out of a vehicle improves fuel efficiency and lowers emissions. That is the main reason aluminium keeps displacing steel in vehicle structures.

Aerospace and electronics follow the same logic: strength to weight in one, and heat dissipation plus shielding in the other.
